Compare PAX terminals
See the difference between PAX SmartECR E600, E700and A800
E500
Android 6.0
Operating system
5"
IPS 1280 x 800 pixels HD color touchscreen
4.3"
TFT WQVGA 480 x 272 pixels payment module touch screen
2 cameras
2MP front + 5MP rear camera
Cortex A57
Quad-core processor
4.0 BLE
Plus WiFi and 4G
2600mAh, 3.77V
Rechargeable li-on battery with 30min backup capacity
3.4kg
Length: 268.2mm
Width: 200mm
Height: 268mm
PCI PTS 5.x SRED
Highest payment security standard
E700
Android 7.1
Operating system
12.5"
IPS 1920 x 1080 pixels FHD color touchscreen
4.3"
TFT WQVGA 480 x 272 pixels payment module touch screen
2 cameras
0.3MP front + 5MP rear camera
Cortex A57
Quad-core processor
4.2 BLE
Plus WiFi, 4G, iBeacon
2550mAh, 3.6V
Rechargeable li-on battery with 30min backup capacity
2.1kg
Length: 310.8mm
Width: 308.9mm
Height: 138.8mm
PCI PTS 5.x SRED
Highest payment security standard
E800
Android 8.1
Operating system
15.6" + 15.6"
HD color touchscreens: IPS 1920 x 1080 pixels
4.3"
TFT WQVGA 480 x 272 pixels payment module touch screen
Rear camera
5MP rear camera
Cortex A17
Quad-core processor
4.0 BLE
Plus, WiFi, 4G
2600mAh, 7.2V
Rechargeable li-on battery with 30min backup capacity
6.4kg
Length: 378.4mm
Width: 377.2mm
Height: 409mm
PCI PTS 5.x SRED
Highest payment security standard
